MC054V RC REMOTE CONTROL MICROWAVE SENSOR
MC054V RC sensor is an innovative and active motion detector with HF system 5.8GHZ. Motion can be deteched through plastic, glass and thin non-metal material.
The sensor allows energy-saving without compromising comfort. When used in combination with 1-10V dimmable LED drivers or ballasts, they can achieve 3 steps dimming function, which is perfect for use in some areas that requires a light change notice before totally switch off.
Also, the infrared remote control design makes customer to adjust the parameters of the sensors easily.
SPECIFICATIONS
- Function: On/Off function, 1-10V Step Dimming
- Operating Voltage: 220-240VAC (50/60Hz)
- Rated Load: 400W(Inductive)
- Standby Power: 0.5W
- IP: 65
- Mounting Height: 15m max
- Working Temperature (℃): -25—60
- Dimming Level: 10%-50%
- Applicable: LED Light
